One, introduction
Closed soft water cooling machine LD-BLS series is a new generation of heat exchange of air cooling machine.The cooling principle is: the use of wet and dry bulb temperature environment, with the aid of cooling wind + water + evaporation endothermic, absorption cooling closed cooling water softener equipment within the cycle of heat into the atmosphere.
Two, applicable scope
1, LD-BLS series of closed soft water cooling machine is applicable to the following various cooling equipment
(L), high frequency induction quenching, heating, melting, thermal insulation; cooling, transformer, inductance of high frequency power supply equipment;
(2), the cooling rectifier equipment, welding equipment, casting equipment;
(3), metal die-casting mold, injection mold and other large mold cooling;
(4), the cooling chemical reaction kettle, electrochemical reactor, large hydraulic oil, hydraulic oil station, silicone oil, heat treatment of quenching medium;
(5), the condenser cooling water cooling chillers of central air-conditioning;
(6), the cooling of large generating units, large motors, diesel engines, hot-air blower, electric power transformer, glass equipment etc.;
(7), all need cooling equipment, apparatus, medium, can use LD-BLS series of closed soft water cooling machine cooling.
2, structure characteristics
LD-BLS series of closed soft water cooling machine adopts copper composite heat conducting element, an internal circulation cooling water.Exchange cooling by wind + water + evaporation endothermic heat absorbed by the heat, cooling equipment, into the atmosphere.Is a new generation of air-cooled heat exchanger unit.Closed soft water cooling machine composite multi-layer calandria cooler, heat flow density is very high, very high thermal conductivity, high cooling efficiency.
LD-BLS series of closed soft water cooling machine does not need water and cooling tower.Use soft water or distilled water through the heat exchanger for a closed cycle, pure water, even if the temperature is high, the cooling system and the circulation line does not form scale effect of equipment cooling or clogged cooling pipes.The cooling system and the circulation line can not enter the impurities, leading to blocked.To increase the reliability of the system.
3, LD-BLS series of closed soft water cooling machine has the following advantages:
(L), direct heat, high heat exchange efficiency.Only one heat exchange, can be heat exchange to the atmospheric environment.
(2), covers an area of small, without digging pool, easy access and convenient
(3), less of pipeline, convenient installation.
(4), water conservation, closed soft water circulating consumption is few, once adding volume of water or distilled water, water is somewhat loss, supplement can.
(5), can be directly cooling water, oils, alcohols, quenching liquid, water, and chemical liquid medium.
(6), using a closed loop, dielectric loss, composition and stability, is not influenced by the environment, no pollution of the environment.
(7), digital temperature display, a water level display, over-temperature alarm, automatic level
